Sludge Drying Systems
Compact continuous indirect thermal dryers — reducing sludge moisture from 85% to approximately 5% using a heated rotating spindle with steam or thermic fluid
Overview
What is Sludge Drying Systems?
Sludge drying systems thermally reduce the moisture content of mechanically dewatered sludge to produce a dry, stable product suitable for beneficial reuse as fuel, fertilizer, or landfill disposal. The indirect drying process transfers heat from steam or thermic fluid through a heated hollow rotating spindle directly to the sludge without combustion gases coming into contact with the sludge material — eliminating exhaust gas contamination and odor release to atmosphere.
The key operating principle is the rotating heated spindle, which provides a very large heat transfer surface area relative to the machine volume. As sludge enters the dryer and contacts the hot spindle surface, moisture evaporates rapidly. The spindle rotation simultaneously conveys the sludge through the dryer and provides a self-cleaning action — continuously wiping the heat transfer surface to prevent sludge from fouling or sticking, which is the primary cause of efficiency loss and maintenance requirements in conventional drum dryers.
The entire drying process takes place in an enclosed, sealed housing with an integrated vapor extraction system that captures evaporated moisture for condensation and disposal. This enclosed operation prevents odor emission to the surrounding environment, making these dryers suitable for installation in or near occupied areas. Construction in stainless steel 304 or 316 provides corrosion resistance across the full range of municipal and industrial sludge types.
Process
How Indirect Sludge Drying Works
Dewatered Sludge Feed
Mechanically dewatered sludge (typically 15–25% dry solids from a screw press, belt press, or centrifuge) is fed continuously into the dryer inlet. Feed rate is controlled automatically to match dryer capacity.
Heated Spindle Rotation
Steam or thermic fluid circulates through the hollow interior of the rotating spindle, maintaining its surface at the required drying temperature. The rotating spindle transfers heat directly to the sludge by conduction — no hot combustion gas contacts the sludge.
Moisture Evaporation
As sludge contacts the hot spindle surface, moisture evaporates rapidly. Evaporated vapor is extracted from the sealed housing by a vapor handling system. The self-cleaning rotation prevents sludge from coating and insulating the spindle surface.
Dried Sludge Discharge
Dried sludge (approximately 90–95% dry solids) exits the dryer at the discharge end and is conveyed to storage or directly to the end-use application. The compact, granular dried product is stable, hygienic, and significantly reduced in volume and weight.
Benefits
Key Advantages
- Lowest steam consumption in class due to high heat transfer area-to-volume ratio
- Indirect process — no combustion gas contact with sludge, no exhaust gas contamination
- Self-cleaning rotating spindle prevents fouling and maintains consistent drying efficiency
- Fully enclosed odor-free operation — suitable for installation near occupied areas
- Continuous non-stop operation with minimal operator attention required
- Stainless steel 304/316 construction for long-term corrosion resistance
- High thermal efficiency reduces operating costs versus direct-fired dryers
- Reduces sludge volume by up to 80% versus dewatered cake — dramatic reduction in disposal costs
- Dried product suitable for use as fuel, soil amendment, or compliant landfill disposal
